Marine Coupling type VULKANS Coupling RATO DS

- Advertisement -

AREAS OF APPLICATION RATO DS

Rigidly mounted engines.

The highly flexible RATO DS coupling has been specially designed for use in installations requiring a high level of torsional flexibility and medium level of misalignment capacity. Supplementing the all-round RATO S. The RATO DS has been developed to offer an application – orientated coupling design. Specially for rigidly mounted ship´s main propulsion. The 3 available stiffnesses enable a good tuning of the system with respect to both the transient and steady-state torsional vibration response. In the tradition of VULKAN Couplings, a backlash free torque transmission is achieved. When required a torque limiting device can be fitted.

BENEFITS

  1. The element design delivers toque transmission without any play.  Optimal heat dissipation ensures functionality and availability of the drive system even under the harshest conditions.

  2. The compact dimensions of the coupling ensure considerable weight reduction and therefore greater efficiency in the drive as well as lower project costs.

Performance Data of VULKANS Coupling RATO DS
Performance Data of VULKANS Coupling RATO DS

Performance Data of VULKANS Coupling RATO DS
Performance Data of VULKANS Coupling RATO DS

VULKANS Couplings RATO DS type 2200
VULKANS Couplings RATO DS type 2200

VULKANS Couplings RATO DS type 2201
VULKANS Couplings RATO DS type 2201

VULKANS Couplings RATO DS type 2300
VULKANS Couplings RATO DS type 2300

VULKANS Couplings RATO DS type 2301
VULKANS Couplings RATO DS type 2301
