Coriolis Mass Flow Meter Rheonik RHM60

- Advertisement -

Features

  • Standard pressure ratings up to 490 bar (7107 psi).
  • Typical measuring ranges between 60 and 3000 kg/min.
  • Repeatability better than 0.05%.
  • Density uncertainty down to 0.5%..
  • Stainless steel case.
  • Temperature ratings from -196 to 350°C (-320 to 662°F).
  • Mass flow uncertainty down to 0.15%.
  • Accurately measure low flow rates down to 45 kg/min.
  • Unique robust torsion driven oscillation system.
  • Process connection customization available.
  • Approved for use in hazardous areas.
  • Remote and compact transmitter versions Available.

Applications

Typical applications include :

  • Plant Balance.
  • Terminal Transfer.
  • Asphalt/Bitumen and Other High Temperature Fluids.
  • Viscous Fluids.
  • Reactor Charging.
  • Batching.
  • Barge, Ship, Rail Car and Truck Filling.

Benefits

  • Torsion oscillator design assures a stable and drift free measurement with excellent signal to noise ratios.
  • Resilient to external noise and vibration.
  • Insensitive to pipe pressure changes.
  • Robust tube wall thickness provides increased operational safety in abrasive applications.
  • Corrosion resistant.
  • Long sensor life guaranteed due to low mechanical stresses in the meter mechanism.
  • No moving parts to wear or fail.

General specification overview

Coriolis Mass Flow Meter Rheonik RHM60 General Specification Overview
Coriolis Mass Flow Meter Rheonik RHM60 General Specification Overview

RHM60LPart Number Code

Coriolis Mass Flow Meter Rheonik RHM60L Part Number Code
Coriolis Mass Flow Meter Rheonik RHM60L Part Number Code
