2NM Bargesafe Solar Barge Light

1
105
Solar Barge Light Application
Solar Barge Light Application

The Sealite BargeSafe™ Solar 2NM is a solar-powered barge light designed to meet UL 1104 and COLREG-72 standards. The LED barge light sets a new standard and incorporates a host of innovative features designed to make the unit extremely user-friendly.
The world-class LED lens is designed and manufactured by Sealite and achieves precise intensity and sectoring requirements from a single LED light source. Made from tough, durable polycarbonate and using the latest high intensity LED and a uniquely designed lens, the BargeSafe™ Solar 2NM light has an incredibly low power consumption.
The light can be installed in minutes, requires no operator intervention and has a permanent ON/OFF switch for easy storage.

Features

  • 2NM visible range.
  • Single, high powered LED for superior light output.
  • Large internal solar module.
  • Certified to UL 1104 & COLREG-72 photometrics.
  • Ultra low power consumption.
  • Precise light sectoring achieved via Sealite’s world-class lens.
  • Installs in seconds – completely self-contained solar/battery light.
  • User-replaceable battery in sealed battery compartment.
  • NiMH battery for long service life & wide temperature range.
  • ON/OFF storage switch.
  • Robust.
  • IP68 waterproof.

Certification

  • Approvals : UL 1104. COLREG-72.
  • IALA: Signal colours compliant to IALA E-200-1.
  • Quality Assurance: ISO9001:2015.
  • Waterproof : IP68.

Technical Specifications •*

2NM Bargesafe Solar Barge Light Technical Specification
2NM Bargesafe Solar Barge Light Technical Specification

Technical Illustration

2NM Bargesafe Solar Barge Light Technical Illustration
2NM Bargesafe Solar Barge Light Technical Illustration

Application

2NM Bargesafe Solar Barge Light Application
2NM Bargesafe Solar Barge Light Application

Related article : AIS Aid to Navigation (AtoN) Transceiver
