Raymarine RayStar130 GPS Receiver with STng / NMEA 2000
Raymarine RayStar130 GPS Receiver with STng / NMEA 2000

RayStar130 GPS

Key Features

  • STng / NMEA 2000 (certified) connectivity.
  • Space Based Augmentation System (SBAS) enabled.
  • WASS, EGNOS, MSAS and GAGAN.
  • <3m accuracy typical, <5m accuracy guaranteed.
  • Very high sensitivity: -162dBm.
  • 50 channel GPS receiver.
  • Low power: 50mA (1 LEN).
GPS Requirments
DisplayDo you require a GPS?
A Series
(A50/A50D, A57/A57D, A70/A70D)
eSeries
(e7, e7D, e95, e97, e125, e127)
cSeries
(c95, c97, c125, c127)
C Series Widescreen
(C90W, C120W, C140W)

Typically you do not require an external GPS because your Multifunction Display incorporates an integrated GPS receiver.

However, there are some circumstances when you may require an external GPS – for example within a steel wheelhouse where the Multifunction Display will not receive GPS signals.

If in doubt, contact your Raymarine dealer who can advise you whether an external GPS is necessary.

E Series Widescreen (E90W, E120W, E140W)

The E Series Widescreen displays do not have an integrated GPS and therefore require an RS130 connected via a SeaTalkng backbone.

C Series Classic
(C80, C120)
E Series Classic
(E80, E120)

Raymarine Classic Multifunction Displays require a SeaTalk1 to SeaTalkng converter to connect an RS130.

Raymarine RayStar130 GPS Receiver with STng / NMEA 2000
Raymarine RayStar130 GPS Receiver with STng / NMEA 2000

Raymarine RS130 GPS Sensor Specifications

Raymarine RS130 External GPS Sensor
Product NumberE32153
Nominal supply voltage12 or 24V DC
Operating voltage range-10% to +30% of nominal supply range
Power consumption50 mA max
Operating temperature -13ºF to 131ºF (-25ºC to +55ºC)
Relative humiditymax 93%
WaterproofIPx6
Supported connection protocolsSeaTalkng: NMEA 2000 (certified) (via DeviceNet adaptor)
SensitivityHigh sensitivity – acquisition down to -162dBm
No. of channels50
Satellite Differential TypeWAAS (United States); EGNOS (Europe); MSAS (Japan); GAGAN (India)
Differential acquisitionAutomatic
Position accuracy (95%)<15m
Position accuracy with SDGPS (95%)<5m
Speed accuracy (95%)<0.3kt
Time to first fix from cold start<2 minutes (< 45 seconds typical)
Geodetic DatumWGS84

CONNECTION

Raymarine RayStar130 GPS Receiver with STng / NMEA 2000 Connection
Raymarine RayStar130 GPS Receiver with STng / NMEA 2000 Connection

Typical Systems

Basic SeaTalkng System with RS130

  1. SeaTalkng Multifunction display.
  2. SeaTalkng Instrument.
  3. SeaTalkng GPS receiver.

    Raymarine RayStar130 GPS Receiver with STng / NMEA 2000 Basic system
    Raymarine RayStar130 GPS Receiver with STng / NMEA 2000 Basic system

Mixed System with RS130

  1. SeaTalk1 Instrument (via SeaTalk to SeaTalkng adaptor cable)
  2. SeaTalk1 to SeaTalkng converter
  3. SeaTalkng Multifunction display
  4. NMEA 0183 DSC VHF Radio
  5. SeaTalkng Autopilot
  6. SeaTalkng GPS receiver

    Raymarine RayStar130 GPS Receiver with STng / NMEA 2000 Mixed system
    Raymarine RayStar130 GPS Receiver with STng / NMEA 2000 Mixed system
RS130 GPS Receiver with SeaTalkng / NMEA2000
Part No.Description
E32153RS130 GPS Receiver
E35018Pole Mount Bracket
A80001In-line terminator

RS130 – What’s in the box?

The RS130 is available with the features, options, and accessories described below.
Refer to the packing list enclosed with your RS130 shipment to determine the actual contents of your package.

Raymarine RayStar130 GPS Receiver with STng / NMEA 2000 In The Box
Raymarine RayStar130 GPS Receiver with STng / NMEA 2000 In The Box
  1. GPS Receiver
  2. Pole Mount Kit
  3. SeaTalkng spur cable (6 metres)
  4. Screw Pack, consisting of:
    • Studs (Qty 2)
    • Thumb nuts (Qty 2)
    • Screws (Qty 2)
  5. Flush Mount Gasket
  6. Mounting template
